Mini Single Gauge Regulator – to fit M10 Disposable Gas Cylinders

£19.00 + VAT

This Mini Single Gauge Regulator is designed to fit all M10-thread disposable gas cylinders, offering a compact and reliable pressure control solution for hobby, DIY and light industrial use. Compatible with Nitrogen, Argon, CO₂, Helium, CO₂/Argon...

Gas Type & Compatibility

  • Compatible Gases: Nitrogen, Argon, CO₂, Helium, CO₂/Argon Mix, CO₂/Nitrogen Mix

  • Application Notes: Suitable for welding gases, carbonation setups, inflating, purging and general workshop use

  • Typical Uses: MIG/TIG welding, hobby welding, craft projects, small-scale gas applications


Regulator Details

  • Regulator Type: Mini single-gauge pressure regulator

  • Bottle Type: For disposable gas cylinders

  • Cylinder Valve Thread: M10 x 1 (standard for disposable bottles)

  • Compatible Bottle Sizes: Fits all standard disposable cylinders including 600 ml, 1L, and 2.2L bottles

  • Gauge Type: Pressure gauge for measuring 0–4 L/min gas flow


Inlet & Outlet Connections

  • Gas Inlet: M10 x 1 thread

  • Gas Outlet: 4 mm push fitting (1/8″ BSP thread)

  • Output Interface: Push-fit suitable for welding hoses and micro-lines


Pressure Ratings

  • Max Inlet Pressure: 130 bar

  • Max Outlet Pressure: 10 bar

  • Flow Adjustment: Manual control knob for fine gas regulation


Dimensions & Build

  • Construction: Compact metal body with protective gauge housing

  • Design: Lightweight regulator ideal for portable and disposable gas systems

  • Finish: Corrosion-resistant coating


Compatibility

Suitable for:
✔ M10 threaded disposable CO₂ bottles
✔ Disposable Argon and Argon/CO₂ mix cylinders
✔ Helium disposable cylinders
✔ CO₂/N₂ mixed cylinders
✔ Portable welding systems, bench welders, hobby equipment

Valve Thread Standard: M10 x 1 disposable cylinder connection (not suitable for BS341 industrial cylinders)



Perfect Regulator for Disposable Bottles

  • Universal M10 Compatibility – Fits all standard M10 threaded disposable gas cylinders including CO₂, Argon, Helium and mixed-gas bottles.

  • Perfect for MIG/TIG Welding – Ideal for hobbyists, DIY users and compact welding setups using disposable gas bottles.

  • Supports Multiple Gas Types – Works with Nitrogen, Argon, CO₂, CO₂/Argon Mix and CO₂/Nitrogen Mix for true multi-purpose use.

  • Integrated Pressure Gauge – Clear single gauge displays gas flow from 0–4 L/min for accurate welding and flow control.

  • Compact, Lightweight Design – Easy to handle, install and use, especially on portable and small-scale gas applications.

  • Robust Metal Construction – Durable body ensures reliability in workshop and garage environments.

  • High Pressure Capability – Rated for 130 bar inlet pressure and 10 bar outlet pressure for safe, consistent performance.

  • Simple Push-Fit Outlet – 4 mm push fitting with 1/8” BSP thread allows fast, secure connection to hoses and equipment.

  • Tool-Free Adjustments – Smooth control knob allows easy and precise flow regulation.

  • Suitable for Up to 2.2L Cylinders – Works with all disposable cylinder sizes up to and including the larger 2.2L bottles.

  • Low Maintenance – Reliable, long-lasting design requiring minimal upkeep.

  • Versatile Applications – Ideal for welding, purging, inflating, craft work and small workshop tasks.

Typical Applications

  • Regulating gas flow for MIG and TIG welding using disposable cylinders

  • Controlling Argon, CO₂ or mixed-gas supply for hobby welding and DIY metalwork

  • Providing a compact regulator solution for small workshop and garage setups

  • Supplying CO₂ or Nitrogen blends for carbonation, purging or pressure testing

  • Helium supply for inflatables, party balloons and light craft applications

  • Portable gas setups where a full-size regulator or cylinder is not practical


Industries That Benefit

✔ Hobbyists & DIY welders
✔ Small fabrication workshops
✔ Automotive repair and hobby garages
✔ Craft, model making & artistic metalwork
✔ Events, party and entertainment setups
✔ Home workshops & portable tool kits



FAQs

As a trusted supplier of gas, we frequently get asked questions about gas safety, the difference between butane and propane, as well as the best uses for our gas products. In this blog, we’ll be answering our most common FAQs.

Yes, nitrogen is widely used for pressure testing and purging because it is inert and does not introduce moisture or oxygen into systems. This makes it suitable for testing pipework, HVAC systems, and other sealed environments. Adams Gas supplies nitrogen bottles commonly used for these professional applications.

MIG/MAG (GMAW): Always uses shielding gas (unless flux-cored gasless wire)
TIG (GTAW): Always uses shielding gas (usually Argon)
MMA/Stick (SMAW): No external gas needed (flux coating provides shielding)

The right MIG welding gas depends on the material you are welding and the finish you want to achieve. Argon and CO2 mixes are commonly used for mild steel, while higher argon blends are better suited to stainless steel and aluminium. Adams Gas offers a wide range of MIG welding gases and can help customers choose the most suitable option for consistent, high quality results.

Pure CO2 is a cost effective option that delivers good penetration, but it can create more spatter and a rougher weld finish. Mixed gases cover cleaner welds, better arc stability, and improved control. Adams Gas supplies both pure CO2 and mixed gas options so welders can choose the right balance between performance and cost.

Pure argon is the most commonly used gas for TIG welding, as it provides a stable arc, clean welds, and precise control. It is suitable for welding materials such as aluminium, stainless steel, and mild steel. Adams Gas supplies high quality TIG welding argon to support consistent, professional results.

In most cases, TIG welding uses pure argon rather than mixed gases. However, certain specialist applications may use argon and helium blends to increase heat input, particularly for thicker materials. Adams Gas offers TIG welding gas options suitable for both standard and more advanced TIG welding requirements.

Yes, TIG welding gas has a direct impact on arc stability, weld appearance, and overall weld quality. Using clean, high purity gas helps prevent contamination, porosity, and inconsistent results. Choosing a reliable supplier like Adams Gas ensures the gas performs consistently across different TIG welding projects.

CO2 bottles are commonly used for MIG welding, particularly on mild steel, where strong penetration and cost efficiency are priorities. They are also used in workshops where high gas consumption makes CO2 a practical option. Adams Gas supplies CO2 bottles suitable for consistent performance in these environments.

Pure CO2 offers deep penetration and lower running costs, making it popular for heavier fabrication work. However, it can produce more spatter and a rougher finish than mixed gases. Many professionals choose CO2 when strength and cost matter more than appearance. Adams Gas provides CO2 bottles that allow users to make that choice confidently.

Bottle size should be chosen based on usage frequency, weld duration, and whether portability or reduced downtime is more important. Smaller bottles suit occasional or mobile work, while larger bottles are better for workshops with continuous welding. Adams Gas offers a range of CO2 bottle sizes to suit different working patterns.

Disposable gas cylinders are most practical for short duration tasks, site work, mobile jobs, or low volume usage where portability and convenience are priorities. They are commonly chosen when returning or storing refillable cylinders is not efficient. Adams Gas supplies disposable gas cylinders suited to these use cases.

Disposable gas cylinders are typically used for light welding, brazing, soldering, heating, and maintenance tasks. They are often ed for repair work, installation jobs, and situations where compact equipment is required. Adams Gas provides disposable gas cylinders suitable for professional and trade applications.

Disposable cylinders offer convenience and portability, while refillable cylinders are generally more cost effective for regular or high volume use. Disposable options are best suited to occasional or mobile work where efficiency and ease of use outweigh long term running costs. Adams Gas offers both disposable and refillable options so users can choose the most efficient solution.

Nitrogen bottles are commonly ed for applications that require an inert, dry, and stable gas supply. These include pressure testing, purging, leak detection support, tyre inflation, laboratory use, and certain industrial processes. Adams Gas supplies nitrogen bottles suitable for professional and trade applications where consistency and reliability are essential.

Choosing the correct nitrogen bottle size depends on usage volume, flow requirements, and whether mobility or reduced changeovers is the priority. Smaller bottles suit site work and intermittent use, while larger cylinders are more efficient for workshops and continuous applications. Adams Gas offers nitrogen bottles in multiple sizes to support different working environments.
